Kingston KVR32S22 3200MHz DDR4 Non-ECC CL22 SODIMM Notebook Value Ram – 8GB

FEATURES

• JEDEC standard 1.5V (1.425V ~1.575V) Power Supply

• VDDQ = 1.5V (1.425V ~ 1.575V)

• 933MHz fCK for 1866Mb/sec/pin

• 8 independent internal bank

• Programmable CAS Latency: 13, 11, 10, 9, 8, 7, 6

• Programmable Additive Latency: 0, CL – 2, or CL – 1 clock

• 8-bit pre-fetch

• Burst Length: 8 (Interleave without any limit, sequential with

starting address “000” only), 4 with tCCD = 4 which does not

allow seamless read or write [either on the fly using A12 or

MRS]

• Bi-directional Differential Data Strobe

• Internal(self) calibration : Internal self calibration through ZQ

pin (RZQ : 240 ohm ± 1%)

• On Die Termination using ODT pin

• Average Refresh Period 7.8us at lower than TCASE 85°C,

3.9us at 85°C < TCASE < 95°C

• Asynchronous Reset

• Height 1.291” (32.80mm) w/heatsink, single sided

Component

CL(IDD) -19 cycles
Row Cycle Time (tRCmin) -45.75ns(min.)
Refresh to Active/Refresh -350ns(min.)
Command Time (tRFCmin)
Row Active Time (tRASmin) -32ns(min.)
Maximum Operating Power -TBD W*
UL Rating -94 V – 0
Operating Temperature -0oC to +85oC
Storage Temperature –55oC to +100oC

*Power will vary depending on the SDRAM used

CL(IDD): 19 cycles Row Cycle
Time (tRCmin): 45.75ns(min.)
Refresh to Active/Refresh Command Time (tRFCmin): 350ns(min.)
Row Active Time (tRASmin): 32ns(min.)
Maximum Operating Power: TBD W*
UL Rating: 94 V – 0
Operating Temperature: 0o C to +85o C
Storage Temperature: -55o C to +100o C

JEDEC standard 1.5V (1.425V ~1.575V) Power Supply
VDDQ = 1.5V (1.425V ~ 1.575V)
800MHz fCK for 1600Mb/sec/pin
8 independent internal bank
Programmable CAS Latency: 11, 10, 9, 8, 7, 6
Programmable Additive Latency: 0, CL – 2, or CL – 1 clock
8-bit pre-fetch
Burst Length: 8 (Interleave without any limit, sequential with
starting address “000” only), 4 with tCCD = 4 which does not
allow seamless read or write [either on the fly using A12 or
MRS]
Bi-directional Differential Data Strobe
Internal(self) calibration : Internal self calibration through ZQ
pin (RZQ : 240 ohm ± 1%)
On Die Termination using ODT pin
Average Refresh Period 7.8us at lower than TCASE 85°C,
3.9us at 85°C < TCASE < 95°C
Asynchronous Reset
PCB : Height 1.180” (30.00mm), double sided component
